Dimensions / Weight
| W | H | D | |
|---|---|---|---|
| Dimensions | 430 mm (16.93 inch) | 88 mm (3.46 inch) | 370 mm (14.57 inch) |
High-Voltage Scanner
TOS9320
TOS9320
290,000円 （税込：319,000円）
- Output can be expanded to four channels with one high-voltage scanner. The electric potential of each channel can be arbitrarily set to high, low, or open, and can be tested at any of these four points.
- Up to four high voltage scanners (total 16 channels) can be connected to each unit.
- Output of each channel and contact with testing points can be easily monitored.
Overview
The high-voltage scanner TOS9320 is a specialized option for the TOS9300 series, capable of rapidly distributing test voltage from the main unit to multiple testing points for withstanding voltage and insulation resistance testing. Channels can be controlled with an external device through the back panel CONTROLLER INTERFACE connector. Remote control is not limited to the TOS9300 series, but is also compatible with previous models such as the TOS5300 series hipot/insulation resistance tester. The TOS9320 high-voltage scanner is an essential tool for the automation of highly reliable testing of electronic devices among multiple channels.
Specifications
Specifications
Basic specifications
| Item | TOS9320 | |
|---|---|---|
| Maximum Operating Voltag | AC | 5 kV |
| DC | 7.2kV | |
| Number of channels | 4 (Each channel can be set to high, low, or open.) | |
| Maximum connections | 4 units. Channel numbers are assigned according to the order in which connections are made to the TOS93 series tester. 1st scanner: CH1 to CH4, 2nd scanner:CH5 to CH8, 3rd scanner: CH9 to CH12, 4th scanner: CH13 to CH16 | |
| Contact check function | Available | |
Display
| Item | TOS9320 |
|---|---|
| DANGER | Lights up in sync with the TOS9300 series tester |
| CHANNEL | Indicates the setting of each channel with color. Red: High, Green: Low, Orange: Contact being checked, Off: Open |
| EXTERNAL | Lights up when external control is on |
| POWER | Lights up when the power is on |
Interface and other functions
| Item | TOS9320 | |
|---|---|---|
| Control switch | EXTERNAL I/O switch for switching the following controls. ON: External control through the CONTROLLER INTERFACE OFF: Control from the TOS93 series tester | |
| CONTROLLER INTERFACE (external control) | D-sub 25-pin connector. | |
| Function | Sets each channel to high or low or all channels to open. Outputs the setting of each channel. | |
| Input | The input signals are all low-active control. The input terminal is pulled up to +12 V by a resistor. Leaving the input terminal open is equivalent to applying a high level signal. | |
| High-level input voltage | 11 V to 15 V | |
| Low-level input voltage | 0 V to 4 V | |
| Low-level input current | -5 mA max. | |
| Input time width | 5 ms min. | |
| Output | Output method | Open collector output (4.5 Vdc to 30 Vdc) |
| Output withstanding voltage | 30 Vdc | |
| Output saturation voltage | Approx. 1.1 V (25 °C) | |
| Maximum output current | 400 mA(TOTAL) | |
| TOS9300 series tester interface | MINI DIN 8-pin connector. Accuracy guaranteed up to 4 units (16 channels) | |
General specifications
| Item | TOS9320 | ||
|---|---|---|---|
| Environment | Installation location | Indoors, 2000 m or less | |
| Warranty range | Temperature | 5°C to 35°C (41°F to 95°F) | |
| Humidity | 20%rh to 70%rh (no condensation) | ||
| Operating range | Temperature | 0°C to 40°C (32°F to 104°F) | |
| Humidity | 20 %rh to 80 %rh (no condensation) | ||
| Storage range | Temperature | -20 °C to 70 °C (-4 °F to 158 °F) | |
| Humidity | 90 %rh or less (no condensation) | ||
| AC line power requirements | Nominal voltage range (allowable voltage range) | 100 Vac to 240 Vac (90 Vac to 250 Vac) | |
| Power | 50 VA max. | ||
| Allowable frequency range | 47 Hz to 63 Hz | ||
| Insulation resistance (between AC LINE and chassis) | 30 MΩ or more (500 Vdc) | ||
| Withstanding voltage (between AC LINE and chassis) | 1500 Vac, 1 minute, 20 mA or less | ||
| Earth continuity | 25 Aac/0.1 Ω or less | ||
| Weight | Approx. 8 kg (17.6 lb) | ||
| Accessories | Power cord (1 pc., length: 2.5 m: The attached power cord varies depending on the shipment destination.) High-voltage test lead [TL31-TOS] (8 red), Lead for high voltage parallelconnection TL33-TOS (1 pair), Interface cable (1 pc.), CONTROLLER INTERFACEplug (1 set), High-voltage warningsticker (2 pc.), Channel labels (For the panel (1 sheet), For the test leads (1 sheet)), User’s manual (1 copy), Safety Information (1 copy) | ||
| Electromagnetic compatibility *1 *2 | Complies with the requirements of the following directive and standards. EMC Directive 2014/30/EU, EN 61326-1 (Class A *3), EN 55011 (Class A *3, Group 1 *4), EN 61000-3-2, EN 61000-3-3 Applicable under the following conditions The maximum length of all cabling and wiring connected to this product is less than 2.5 m. A shielded cable is used for the connection to the CONTROLLER INTERFACE. The high-voltage test lead TL31-TOS is in use.Electrical discharges are applied only to the EUT. | ||
| Safety | Complies with the requirements of the following directive and standards. Low Voltage Directive 2014/35/EU *2, EN 61010-1 (Class I *5 , Pollution Degree 2 *6) | ||
*1 Does not apply to specially ordered or modified products. *2 Only on models that have CE/UKCA marking on the panel. *3 This is a Class A instrument. This product is intended for use in an industrial environment. This product may cause interference if used in residential areas. Such use must be avoided unless the user takes special measures to reduce electromagnetic emissions to prevent interference to the reception of radio and television broadcasts. *4 This is a Group 1 instrument. This product does not generate and/or use intentionally radio-frequency energy, in the form of electromagnetic radiation, inductive and/or capacitive coupling, for the treatment of material or inspection/analysis purpose. *5 This is a Class I instrument. Be sure to ground this product’s protective conductor terminal. The safety of this product is guaranteed only when the product is properly grounded. *6 Pollution is addition of foreign matter (solid, liquid or gaseous) that may produce a reduction of dielectric strength or surface resistivity. Pollution Degree 2 assumes that only non- conductive pollution will occur except for an occasional temporary conductivity caused by condensation.
