Application Software for Power Supplies and Electronic Loads
WAVY Series
wavy
60,000円 – 80,000円
- Easily create and edit the test conditions data for sequence operation.
- Easily manage test conditions template using the function for saving test condition data files.
- The execution graph function displays the execution status as a cursor on the settings graph, and can be used to verify the progress of the execution sequence.
- The “monitor graph,” which plots monitor values during execution, allows intuitive observation of actual output. (Available from Ver. 4.0)
- The acquired monitor data can be saved as the test results.
| Image | SKU | Ver | 標準価格 | WEBかんたんお見積り | |
|---|---|---|---|---|---|
 | SD024-PAV (Wavy for PAV) | PAV Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD022-PBZ（Wavy for PBZ） | PBZ Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD027-PWR-01（Wavy for PWR-01） | PWR-01 Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| Wavy for PAS & PWR | PAS / PWR Series | Ver.5.0 | 60,000円 （税込：66,000円） | |
| Wavy for PAT-T | PAT-T Series | Ver.5.1 | 60,000円 （税込：66,000円） | |
| Wavy for PAG | PAG Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD013-PWX (Wavy for PWX) | PWX Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD025-PMX (Wavy for PMX) | PMX-A Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD032-PCR-WE/WEA（Wavy for PCR-WE & PCR-WEA） | PCR-WE/WE2 / PCR-WEA/WEA2 Series | Ver.6.1 | 60,000円 （税込：66,000円） | |
| SD011-PCR-LE (Wavy for PCR-LE) | PCR-LE Series | Ver.5.5 | 60,000円 （税込：66,000円） | |
| SD023-PLZ-5W(Wavy for PLZ-5W) | PLZ-5W Series | Ver.5.0 | 60,000円 （税込：66,000円） | |
| SD033-PLZ-5WH2（Wavy for PLZ-5WH2） | PLZ-5WH2 Series | Ver.5.0 | 60,000円 （税込：66,000円） | |
| Wavy for PLZ-4W | PLZ-4W/PLZ-4WL/PLZ-4WH Series | Ver.5.3 | 60,000円 （税込：66,000円） | |
| Wavy for PLZ-U | PLZ-U Series | Ver.3.2 | 80,000円 （税込：88,000円） | |
| Wavy for PCZ1000A | PCZ1000A | Ver.6.0 | 60,000円 （税込：66,000円） |
Line-up
| Image | SKU | Ver | 標準価格 | WEBかんたんお見積り | |
|---|---|---|---|---|---|
| SD024-PAV (Wavy for PAV) | PAV Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD022-PBZ（Wavy for PBZ） | PBZ Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD027-PWR-01（Wavy for PWR-01） | PWR-01 Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| Wavy for PAS & PWR | PAS / PWR Series | Ver.5.0 | 60,000円 （税込：66,000円） | |
| Wavy for PAT-T | PAT-T Series | Ver.5.1 | 60,000円 （税込：66,000円） | |
| Wavy for PAG | PAG Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD013-PWX (Wavy for PWX) | PWX Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD025-PMX (Wavy for PMX) | PMX-A Series | Ver.6.0 | 60,000円 （税込：66,000円） | |
| SD032-PCR-WE/WEA（Wavy for PCR-WE & PCR-WEA） | PCR-WE/WE2 / PCR-WEA/WEA2 Series | Ver.6.1 | 60,000円 （税込：66,000円） | |
| SD011-PCR-LE (Wavy for PCR-LE) | PCR-LE Series | Ver.5.5 | 60,000円 （税込：66,000円） | |
| SD023-PLZ-5W(Wavy for PLZ-5W) | PLZ-5W Series | Ver.5.0 | 60,000円 （税込：66,000円） | |
| SD033-PLZ-5WH2（Wavy for PLZ-5WH2） | PLZ-5WH2 Series | Ver.5.0 | 60,000円 （税込：66,000円） | |
| Wavy for PLZ-4W | PLZ-4W/PLZ-4WL/PLZ-4WH Series | Ver.5.3 | 60,000円 （税込：66,000円） | |
| Wavy for PLZ-U | PLZ-U Series | Ver.3.2 | 80,000円 （税込：88,000円） | |
| Wavy for PCZ1000A | PCZ1000A | Ver.6.0 | 60,000円 （税込：66,000円） |
Overview
Software to support automated testing of power supplies and electronic load devices
Wavy” is software that supports the creation and execution of sequences for Kikusui’s power supply units. To create a program, it is necessary either to operate the power supply unit or remote control panel, or to create a program on a personal computer using BASIC or C. However, the PBZ series and PLZ-5W series are equipped with a function to control output sequences.
On the other hand, a personal computer makes it easier to grasp the overall program and waveform image, but is somewhat difficult for users who are not familiar with programming languages. Wavy is a very easy to use program.
Wavy was developed with the goal of making it easy for even those who know nothing about programming languages to create the sequence patterns they want using a personal computer.
Ver. 4.0 is equipped with a “real-time graph monitoring function” for monitoring and logging of voltage and current, and Ver. 5.0 has a “direct control function” that allows users to operate the power supply as if using a remote control.
Supported Models / Operating Environment
Wavy can control only one power supply and one electronic load. (Wavy for PLZ-U is one frame.)
Supported models
| Supported model name | Required Interface Environment | Model | Hardware Sequence *1 (number of steps) | Software Sequence*2 (number of steps) | Operation mode | |
|---|---|---|---|---|---|---|
| DC Power Supply | PAV Series | Not required (RS232C, USB as standard equipment / LAN option) | SD024-PAV（Wavy for PAV） | ✓（12） | ✓（1024） | CV,CC |
| PBZ Series | Not required (RS232C, GPIB, USB as standard equipment / LAN option) | SD022-PBZ (Wavy for PBZ) | ✓（1024） | − | CC,CV／DC,AC+DC | |
| PWR-01 Series | Not required (RS232C, USB, LAN, standard equipment) *4 | SD027-PWR-01（Wavy for PWR-01） | ✓（64） | ✓（1024） | CV,CC | |
| PAS, PWR Series | Required separately (PIA4830/4850) | Wavy for PAS PWR | − | ✓（1024） | CV,CC | |
| PAT-T Series | Not required (RS232C standard equipment) *3 | Wavy for PAT-T | − | ✓（1024） | CV,CC | |
| PAG Series | Not required (RS232C standard equipment) *4 | Wavy for PAG | − | ✓（1024） | CV,CC | |
| PWX Series | Not required (RS232C, USB, LAN, standard equipment) *4 | SD013-PWX（Wavy for PWX） | − | ✓（1024） | CV,CC | |
| PMX-A Series | Not required (RS232C, USB, LAN, standard equipment) *4 | SD025-PMX（Wavy for PMX）*6 | − | ✓（1024） | CV,CC | |
| AC Power Supply | PCR-WEA/WEA2 Series | Not required (RS232C, USB, LAN, standard equipment) *4 | SD032-PCR-WE （Wavy for PCR-WE） | ✓（600） | − | CV(AC,DC,AC+DC) |
| SD019-PCR-LE/WE（Wavy Smart Grid Edition） | ✓（600） | − | CV(AC,DC,AC+DC) | |||
| SD020-PCR-LE/WE（Wavy Smart Grid Edition） | ✓（600） | − | CV(AC,DC,AC+DC) | |||
| PCR-LE Series | Not required (RS232C standard equipment) *5 | SD011-PCR-LE（Wavy for PCR-LE） | ✓（600） | − | CV(AC,DC,AC+DC) | |
| SD019-PCR-LE/WE（Wavy Smart Grid Edition） | ✓（600） | − | CV(AC,DC,AC+DC) | |||
| SD020-PCR-LE/WE（Wavy Smart Grid Edition） | ✓（600） | − | CV(AC,DC,AC+DC) | |||
| PCR-M Series | Not required (USB and LAN are standard) *4 | Wavy for PCR-M | − | ✓（2048） | CV(AC,DC,AC+DC) | |
| Electronic Load | PLZ-5W Series | Not required (RS232C, USB, LAN, standard equipment) *4 | SD023-PLZ-5W（Wavy for PLZ-5W） | ✓（10000） | − | CV,CC,CR,CP |
| PLZ-5WH2 Series | Not required (RS232C, USB, LAN, standard equipment) *4 | SD033-PLZ-5WH2（Wavy for PLZ-5WH2） | ✓（10000） | − | CV,CC,CR,CP | |
| PLZ-4W Series,. PLZ-4WL series | Not required (RS232C, GPIB, USB standard) | Wavy for PLZ-4W | ✓ (Normal mode 256, Fast mode 1024) | − | CV,CC,CR,CP | |
| PLZ-U Series | Not required (GPIB, RS232C standard) | Wavy for PLZ-U | ✓（256） | ✓（1024） | CC,CV,CR,CC+CV,CR+CV |
*1 Hardware Sequence” is to control the device by using the Sequence function in the device itself. *2 “Software Sequence” means that the device is controlled by Wavy (software) to perform Sequence control. *3 USB, GPIB, and LAN for PAT-T series are required separately. *4 GPIB is separately required for PWR-01 series, PAG series, PWX series, PMX-A series, PCR-WEA/WEA2 series, PCR-M series, PLZ-5W series, PLZ-5WH2 series, and PCZ1000A. *5 USB, GPIB, and LAN for PCR-LE series are required separately. *6 5-step limited free version (Wavy for PMX Free) is available.
Operating environment
| Supported OS | Windows Ver. | |||
|---|---|---|---|---|
| Wavy Ver. | 10(x86/x64) | 8(x86/x64) | 7(x86/x64) | Vista *1 |
| 6.X | ✓ | ✓ | ✓ | ✓ |
| 5.X | ✓ | ✓ | ✓ | ✓ |
| 3.2 | – | ✓ | ✓ | – |
*1 32bi version only
SD019-PCR-LE/WE、SD020-PCR-LE/WEの場合
| Supported OS | Windows Ver. | |||
|---|---|---|---|---|
| Wavy Ver. | 10(x86/x64) | 8(x86/x64) | 7(x86/x64) | VISTA |
| 1.2 | – | ✓ | ✓ | – |
| CPU | Pentium IV or later (Core 2 or later) |
|---|---|
| CD-ROM | Required when setting up Wavy |
| mouse | required |
| monitor | 1024 x 768 or higher |
| memory | Windows 10, Windows 8, Windows 7 (2GB or more) Vista (1.5GB or more) |
| Hard Disk Capacity | Sufficient free space to store files |
Interface environment
Supported interfaces: USB, RS232C, GPIB, LAN
In case of GPIB, the GPIB driver provided by the following companies must be installed and operational.
- NI-488.2 driver provided by National Instruments
- API-GPIB (98/PC) W95, NT Ver3.50 or higher for GPIB communication driver by CONTEC
- Japanese Windows version GPC-4301 Ver.1.10-06 or higher made by Interface Inc.
- KEYSIGHT Inc. 82357B USB/GPIB (supported by Wavy Ver. 5.0 or higher)
The following interfaces can also be used (verified)
- USB-CVRS9 (USB-RS232C) by Sanwa Supply Co.
- I-O DATA SB-RSAQ3R (USB-RS232C)
- REX-USB60F (USB-RS232C) by RATOC Systems, Inc.
- REX-USB60(USB-RS232C) by RATOC Systems, Inc.
- REX-USB220 (USB2.0 to GPIB Converter)
- REX-5052 (GPIB PC Card)
※We do not guarantee the combination (operation) of the PC and each interface. Please note that we do not guarantee the combination (operation) of the PC and each interface.
Notes.
- Cable for PC connection is not included. (For RS232C, please prepare a crossover cable.)
- RS232C control using a USB-RS232C converter may not work properly.
- Wavy does not support the hardware sequence chain and pause functions.
Trial Version Download
No functional limitations!
Free 3-week trial
This is a trial version of “Wavy” software to support sequence creation and execution of Kikusui Electronics power and load devices. This trial version can be tried out for 3 weeks from the time of startup (there are no functional limitations other than the usage period).
*The other Wavy trial versions will not be able to be run on the PC after 3 weeks have passed after running the Wavy trial version. If you are unable to run the application, please try running it with administrator privileges.
The software on this site is provided free of charge subject to the terms of this License Agreement. By downloading this software, you agree to be bound by the terms of this License Agreement. If you do not agree to the terms of this license agreement, you may not download the software listed below. Please be sure to read the “Download Precautions” before downloading the software.
Notes on downloading *Please be sure to read
- Software License Agreement
- Kikusui Electronics Corporation (hereinafter referred to as “the Company”) grants you the following rights with respect to the software and related materials (hereinafter referred to as “the Software”) that are made available for download upon acceptance of this License Agreement. (a) You may use the Software for the purpose of using our products corresponding to the Software. (b) You may copy the Software and use it on one or more computers.
- >Any files created as a result of using the Software in accordance with the stated purpose become your copyrighted work.
- Copyright The copyright of this software and its copies are held by the Company or by parties authorized by the Company, and is protected by the Copyright Act of Japan and international treaties. Any copy of the software made by the customer under this license agreement must bear the same copyright notice as the one attached to the downloaded software.
- Prohibitions (a) If the Software is provided as source code, you may not distribute modified versions of the Software to any third party. (b) If the Software is provided in binary form, you may not reverse engineer the Software.
- The Company does not warrant that the Software will be suitable or useful for your particular purpose, that the Software is free from defects, or any other warranty of any kind with respect to the Software.
- In no event shall the Company be liable for any damages (including, but not limited to, damages to business profits, business interruption, loss of business information, or other monetary damages) arising out of the use or inability to use this software.
- >Termination of the Agreement If the customer violates this license agreement, the Company may terminate this license agreement. If such a case arises, the customer shall cease use of this software.
- Support
- If you have any questions about the software, please contact our service (service@kikusui.co.jp). Please be sure to read the documentation file after extracting the files.
- Scope of Warranty
- Downloading and installing the software is the sole responsibility of the user.
- The software is subject to improvement and change without notice.
- Copyright holder
- The copyright of each software belongs to Kikusui Electronics Industry Co.
